Where to find the current PEOPLE / PPL result
The active provable output of the saved configuration is FLUX decode 53, written by node 730. HQ / upscale and the final overlay chain exist but are stored in BYPASS.
Two output levels
Direct JPG after main FLUX decode. This is the first verification point for the saved configuration.
Save nodes exist, but their upscale / overlay upstream is stored in mode 4.
Prefix, format and route state
- upstream
- 53
- folder
- ph\[time(%Y-%m-%d)]
- prefix
- ph01_archviz_sdxl2flux_LQ1
- file
- JPG · 72 dpi · Q100
- upstream
- 833
- folder
- ph\[time(%Y-%m-%d)]
- prefix
- ph01_archviz_sdxl2flux_HQ
- file
- PNG · 300 dpi · Q100
- upstream
- 849
- folder
- ph\[time(%Y-%m-%d)]
- prefix
- ph01_archviz_sdxl2flux_LQ2
- file
- JPG · 72 dpi · Q100
Confirmed segment and full template
ph\[time(%Y-%m-%d)]ph01_archviz_sdxl2flux_LQ1not stored in the workflow JSON<ACTIVE_COMFYUI_ROOT>\output\ph\<YYYY-MM-DD>\ph01_archviz_sdxl2flux_LQ1_....jpgThe value stays in this browser and does not modify the workflow.
Six visual checkpoints
A · 79B · 779A · 53B · 779A · 53B · 833A · 451B · 459A · 509B · 552A · 25B · 833Show the full PreviewImage index
39 ← 38 · 167 ← 165 · 233 ← 232 · 581 ← 583
113 ← 550 · 340 ← 339 · 341 ← 346 · 342 ← 347 · 343 ← 350 · 344 ← 349 · 345 ← 348 · 351 ← 352 · 353 ← 354
409 ← 829 · 507 ← 503 · 508 ← 522
15 ← 849
Previously created images
01File paths
- Source path
- Generated neutral placeholder · 2026-09-27
- Static project
- /assets/output/atlas-neutral-01.jpg
02File paths
- Source path
- Generated neutral placeholder · 2026-09-27
- Static project
- /assets/output/atlas-neutral-02.jpg
03File paths
- Source path
- Generated neutral placeholder · 2026-09-27
- Static project
- /assets/output/atlas-neutral-03.jpg
04File paths
- Source path
- Generated neutral placeholder · 2026-09-27
- Static project
- /assets/output/atlas-neutral-04.jpg
The original path is shown for provenance. The site uses only the stable copy from public/assets/output; the TEMP file may be removed by the system.
Fan-out reference image
NOT CONFIRMED The semantics of the external receiver UUID are not proven by the serialized graph.
Current active file: node 53 → node 730
After the PEOPLE composite returns to the main pipeline, the active chain reaches VAEDecode 53. Its image feeds Image Save LQ 730 directly; this is the first place to verify that people survived into the current final frame.
Primary inspection point
In the saved workflow, node 730 is the active write point for the direct result of node 53.
Specific output file
The workflow JSON does not prove that the current run completed or that a file was actually written to disk.
| Node | Role | Confirmed value |
|---|---|---|
| 53 | VAEDecode after the main FLUX stage | Active upstream for save 730 |
| 730 | Image Save LQ | JPG · 72 dpi · quality 100 |
| Folder | Serialized subfolder | ph\[time(%Y-%m-%d)] |
| Prefix | Result name | ph01_archviz_sdxl2flux_LQ1 |
How to read the path without inventing facts
The JSON stores only the relative folder and prefix. The absolute root depends on the ComfyUI instance that is actually running. The serialized segment and the expected resolution against the standard output directory are therefore documented separately.
Stable serialized segment
ph\[time(%Y-%m-%d)] + ph01_archviz_sdxl2flux_LQ1 are stored in node 730.
Absolute filesystem root
The technical archive does not contain a confirmed path to the active ComfyUI output root.
HQ and overlay are a separate route that is currently disabled
UltimateSDUpscale 833 and related sizing / overlay nodes 832–851 are stored in mode 4 (BYPASS). Their save points are documented but are not the current active final.
Saved mode
Nodes 833, 834 and overlay nodes 832–851 have mode 4 / BYPASS.
Runtime HQ result
A valid HQ / overlay file requires a separate run with the chain enabled.
| Route | Output | Saved-graph state |
|---|---|---|
| 53 → 834 → 833 → 531 | ph01_archviz_sdxl2flux_HQ · PNG · 300 dpi | BYPASS upstream |
| 53 → 833 → 848 → 849 → 293 | ph01_archviz_sdxl2flux_LQ2 · JPG · 72 dpi | BYPASS overlay chain |
| 849 → 15 | Preview FINAL IMAGE | Available after the overlay chain is enabled |
| 53 / 833 → 141 | Image Comparer FLUX / UPSCALE | Use after HQ is enabled |
Which previews and comparers to inspect before delivery
| Node | Shows / compares | When to use it |
|---|---|---|
| 409 | Raw PPL decode 829 | Prove that people were generated |
| 480 | MASK / PPL: 451 vs 459 | Verify placement and selected composite |
| 518 | Inpaint composite 509 vs source 552 | Verify INPUT / 3D path |
| 72 | SDXL / FLUX: 779 vs 53 | Inspect the main FLUX change |
| 141 | FLUX / UPSCALE: 53 vs 833 | Only after HQ is enabled |
| 15 | Preview FINAL IMAGE from 849 | Only after the overlay chain is enabled |
When the output can be considered verified
- People are visible in 409 and match prompt 408.
- Comparer 480 shows the correct mask and selected composite.
- People remain after main FLUX decode 53.
- A file with the LQ1 prefix exists in the current-date folder.
- If the HQ chain is enabled manually: 141, 531, 293 and Preview 15 are verified separately.
